Technical Specifications
Code:
45510 (Black) - 45351 (White)
Configuration:
2 way
Recommended amplifier:
80W
Long Term power:
---
Short term power:
---
Nominal impedance:
8Ohm
Frequency response:
150Hz - 20KHz
Low Frequency woofer:
2 x 3'' - 0.75'' coil
High frequency driver:
1'' dome
Sensitivity (@1W/1m):
88
Maximum SPL cont/peak:
100 (1 m) dB
Dispersion:
125°x70° HxV (2kHz)
Crossover Frequency:
---
Recommended HP filter:
100hz - 24dboct
Recommended external filter:
---
Input connector:
ceramic screw bloc
Net Dimension (WxHxD):
100x243x125mm / 3.93x9.56x4.92 inch
Net Weight:
1.5Kg / 3.30Lb
